Premium Efficiency NEMA Standard Motor 1HP 2HP 3HP 5HP Three Phase Induction Motor

Brand Name : BM

Model Number : NEMA 184T

Certification : UL

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T

Supply Ability : 1000PC per Month

Delivery Time : 30 days

Packaging Details : Carton/Pallet

Efficiency : Premium Efficiency

Power : 1HP-5HP

Speed : 2900rpm

Voltage : 380V

Frequency : 60 Hz

Service Factor : 1.15

Contact Now

NEMA Standard 1HP 2HP 3HP 5HP Premium Efficiency Three Phase Induction Motor

1, Suitable for air-over applications such as aeration fans, exhaust fans and other air handling units.

2, Motors that provide high starting torque for the most demanding applications.

* 40°C Ambient
* Continuous Duty
* Max Elevation 3300ft
* High Torque
* Class B Insulation up to 3HP; Class F Insulation 3-10HP
* Class B Temperature Rise
* Capacitor Start, Induction Run .33-1.5HP; Capacitor Start, Capacitor Run 2-10HP

HP	RPM	FRAME	VOLTAGE	FULLLOAD AMPS @230V	S.F
1/3	1725	56/56C	1115/208-230	3.3	1.15
1/3	3450	156/56C	115/208-230	3.1	1.15
1/2	11725	56/56C	1115/208-230	4.4	1.15
1/2	3450	56/56C	1115/208-230	4.0	1.15
3/4	1725	56/56C	115/208-230	5.5	1.15
3/4	13450	56/56C	1115/208-230	5.3	1.15
1	1725	56/56C	1115/208-230	6.0	1.15
1	3450	156/56C	1115/208-230	5.6	1.15
1-1/2	11725	156/56C	1115/208-230	7.6	1.15
1-1/2	13450	156/56C	1115/208-230	7.1	1.15
1 1/2	3450	56	1115/208-230	7.1	1.00
1 1/2	:3450	143T	1115/208-230	7.1	1.00
1 1/2	1725	56	1115/208-230	7.6	1.15
1 1/2	1725	1145T	1115/208-230	7.6	1.00
2	13450	56	1115/208-230	9.0	1.15
2	3450	145T	1115/208-230	9.0	1.15
2	1725	56	115/208-230	9.2	1.15
2	1725	1145T	208-230	9.2	1.15
3	3450	56H	115/208-230	13.0	1.15
3	3450	145T	208-230	13.0	1.15
3	1725	184T	208-230	13.5	1.15
5	3450	184T	208-230	20.0	1.15
5	1725	184T	208-230	21	1.15
7 1/2	3450	213T	208-230	32	1.00
7 1/2	1725	215T	208-230	32	1.15
10	3800	215T	208-230	141.5	1.15
